HPE FlexNetwork 5510 HI Series Acl And Qos Configuration Guide

74
When flow 1 is not present, flow 2 is transmitted at the maximum rate, 128 kbps. When both flows are
present, the traffic rate of flow 2 might drop below this rate, because the total rate of the two flows
cannot exceed 192 kbps.
Configuring aggregate CAR
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Configure an aggregate
CAR action.
qos car
car-name
aggregative cir
committed-information-rate [
cbs
committed-burst-size [
ebs
excess-burst-size ] ] [
green
action |
red
action |
yellow
action ] *
qos car
car-name
aggregative cir
committed-information-rate [
cbs
committed-burst-size ]
pir
peak-information-rate [
ebs
excess-burst-size ] [
green
action |
red
action |
yellow
action ] *
Use either of the
commands.
By default, no aggregate
CAR action is configured.
3. Enter traffic behavior
view.
traffic behavior
behavior-name N/A
4. Use the aggregate CAR
in the traffic behavior.
car name
agg-car-name N/A
Configuring hierarchical CAR
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Configure a hierarchical
CAR action.
qos car
hierarchy-car-name
hierarchy
cir
committed-information-rate [
cbs
committed-burst-size [
ebs
excess-burst-size ] ]
qos car
hierarchy-car-name
hierarchy
cir
committed-information-rate [
cbs
committed-burst-size ]
pir
peak-information-rate [
ebs
excess-burst-size ]
Use either of the commands.
By default, no hierarchical
CAR action is configured.
3. Enter traffic behavior view.
traffic behavior
behavior-name N/A
4. Use the hierarchical CAR
action in the traffic behavior
to cooperate with an
aggregate CAR action or
common CAR action.
• Aggregate CAR:
car name agg-car-name
hierarchy-car hierarchy-car-name
[ mode { and | or } ]
• Common CAR:
car cir committed-information-rate
[ cbs committed-burst-size [ ebs
excess-burst-size ] ] [ green action |
red action | yellow action ] *
[ hierarchy-car
hierarchy-car-name [ mode { and |
or } ] ]
car cir committed-information-rate
[ cbs committed-burst-size ] pir
peak-information-rate [ ebs
Use any of the commands.
By default, no hierarchical
CAR action is used in a traffic
behavior.
For more information about
common CAR actions, see
"Configuring traffic policing,
GT
S, and rate limit."
