86
Figure 28 802.1Q tag header
Table 12 Description on 802.1p priority
802.1p priority (decimal) 802.1p priority (binary) Description
0 000 best-effort
1 001 background
2 010 spare
3 011 excellent-effort
4 100 controlled-load
5 101 video
6 110 voice
7 111 network-management
EXP values
The EXP field is in MPLS labels for MPLS QoS purposes.
Figure 29 MPLS label structure
As shown in Figure 29, the EXP field is 3-bit long and is in the range of 0 to 7.
