48
Step Command Remarks
queuing.
4. Assign a queue to the SP
group.
qos wrr
queue-id
group
sp
By default, all the queues of a WRR-enabled
port are in WRR group 1.
5. Assign a queue to a WRR
group, and set the
scheduling weight for the
queue.
qos wrr
queue-id
group
1
{
weight
|
byte-count
}
schedule-value
Select
weight
or
byte-count
according to
the type (byte-count or packet-based) of
WRR you have enabled.
By default, all queues are in WRR group 1,
and the weights of queues 0 through 7 are 1,
2, 3, 4, 5, 9, 13, and 15, respectively.
Configuration example
1. Network requirements
{ Configure SP+WRR queuing on GigabitEthernet 1/0/1, and use byte-count WRR.
{ Assign queues 4 through 7 on GigabitEthernet 1/0/1 to the SP group.
{ Assign queues 0, 1, 2, and 3 on GigabitEthernet 1/0/1 to WRR group 1, with the weights
being 1, 2, 1, and 3, respectively.
2. Configuration procedure
# Enter system view.
<Sysname> system-view
# Configure SP+WRR queuing on GigabitEthernet1/0/1.
[Sysname] interface GigabitEthernet 1/0/1
[Sysname-GigabitEthernet1/0/1] qos wrr byte-count
[Sysname-GigabitEthernet1/0/1] qos wrr 4 group sp
[Sysname-GigabitEthernet1/0/1] qos wrr 5 group sp
[Sysname-GigabitEthernet1/0/1] qos wrr 6 group sp
[Sysname-GigabitEthernet1/0/1] qos wrr 7 group sp
[Sysname-GigabitEthernet1/0/1] qos wrr 0 group 1 byte-count 1
[Sysname-GigabitEthernet1/0/1] qos wrr 1 group 1 byte-count 2
[Sysname-GigabitEthernet1/0/1] qos wrr 2 group 1 byte-count 1
[Sysname-GigabitEthernet1/0/1] qos wrr 3 group 1 byte-count 3
Configuring SP+WFQ queuing
Configuration procedure
To configure SP+WFQ queuing:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enter interface view.
interface
interface-type
interface-number
N/A
3. Enable byte-count or
packet-based WFQ
queuing.
qos wfq
[
byte-count
|
weight
]
The default queuing algorithm on an
interface is WRR.
4. Assign a queue to the SP
group.
qos wfq
queue-id
group
sp
By default, all the queues of a
WFQ-enabled port are in WFQ group 1.
5. Assign a queue to a WFQ
group, and set a scheduling
qos wfq
queue-id
group
1
{
weight
|
byte-count
}
Select
weight
or
byte-count
according
to the type (byte-count or
