Step Command Remarks
weight for the queue.
schedule-value
packet-based) of WFQ you have
enabled.
If you have enabled WFQ on the port,
all the queues are in WFQ group 1 by
default and the default scheduling
weight is 1 for each queue.
6. (Optional.) Set the minimum
guaranteed bandwidth for
the queue.
qos bandwidth queue
queue-id
min
bandwidth-value
The default setting is 64 kbps for each
queue in a WFQ group.
Configuration example
1. Network requirements
{ Configure SP+WFQ queuing on interface GigabitEthernet 1/0/1, and use packet-based
WFQ.
{ Assign queues 4 through 7 to the SP group.
{ Assign queues 0, 1, 2, and 3 to the WFQ group, with the weights being 1, 2, 1, and 3,
respectively.
{ Set the minimum guaranteed bandwidth to 128 Mbps for each of the four queues.
2. Configuration procedure
# Enter system view.
<Sysname> system-view
# Configure SP+WFQ queuing on GigabitEthernet 1/0/1.
[Sysname] interface GigabitEthernet 1/0/1
[Sysname-GigabitEthernet1/0/1] qos wfq weight
[Sysname-GigabitEthernet1/0/1] qos wfq 4 group sp
[Sysname-GigabitEthernet1/0/1] qos wfq 5 group sp
[Sysname-GigabitEthernet1/0/1] qos wfq 6 group sp
[Sysname-GigabitEthernet1/0/1] qos wfq 7 group sp
[Sysname-GigabitEthernet1/0/1] qos wfq 0 group 1 weight 1
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 4 min 128000
[Sysname-GigabitEthernet1/0/1] qos wfq 1 group 1 weight 2
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 5 min 128000
[Sysname-GigabitEthernet1/0/1] qos wfq 2 group 1 weight 1
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 6 min 128000
[Sysname-GigabitEthernet1/0/1] qos wfq 3 group 1 weight 3
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 7 min 128000
Displaying and maintaining queuing
Execute display commands in any view.
Task Command
Display SP queuing configuration.
display qos queue sp interface
[ interface-type
interface-number ]
Display WRR queuing configuration.
display qos queue wrr interface
[ interface-type
interface-number ]
Display WFQ queuing configuration.
display qos queue wfq interface
[ interface-type
