47
Step Command Remarks
By default, all queues are in WFQ
group 1 and have a weight of 1.
5. (Optional.) Set the minimum
guaranteed bandwidth for a
WFQ queue.
qos bandwidth queue
queue-id
min
bandwidth-value
The default setting is 64 kbps for
each queue.
Configuration example
1. Network requirements
{ Configure byte-count WFQ queuing on interface GigabitEthernet 1/0/1.
{ Assign queues 0 through 7 to the WFQ group, with their weights being 1, 1, 2, 5, 10, 10, 10,
and 10, respectively.
{ Set the minimum guaranteed bandwidth to 100 Mbps for each queue.
2. Configuration procedure
# Enter system view.
<Sysname> system-view
# Configure byte-count WFQ queuing on interface GigabitEthernet 1/0/1.
[Sysname] interface GigabitEthernet 1/0/1
[Sysname-GigabitEthernet1/0/1] qos wfq byte-count
[Sysname-GigabitEthernet1/0/1] qos wfq 0 group 1 byte-count 1
[Sysname-GigabitEthernet1/0/1] qos wfq 1 group 1 byte-count 1
[Sysname-GigabitEthernet1/0/1] qos wfq 2 group 1 byte-count 2
[Sysname-GigabitEthernet1/0/1] qos wfq 3 group 1 byte-count 5
[Sysname-GigabitEthernet1/0/1] qos wfq 4 group 1 byte-count 10
[Sysname-GigabitEthernet1/0/1] qos wfq 5 group 1 byte-count 10
[Sysname-GigabitEthernet1/0/1] qos wfq 6 group 1 byte-count 10
[Sysname-GigabitEthernet1/0/1] qos wfq 7 group 1 byte-count 10
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 0 min 100000
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 1 min 100000
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 2 min 100000
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 3 min 100000
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 4 min 100000
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 5 min 100000
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 6 min 100000
[Sysname-GigabitEthernet1/0/1] qos bandwidth queue 7 min 100000
Configuring SP+WRR queuing
Configuration procedure
To configure SP+WRR queuing:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enter interface view.
interface
interface-type
interface-number
N/A
3. Enable byte-count or
packet-based WRR
qos wrr
{
byte-count
|
weight
}
By default, all ports use WRR queuing.
