Step
Command
Remarks
16. Enter interface view.
• Enter Layer 2 Ethernet interface view:
interface interface-type
interface-number
• Enter Layer 2 aggregate interface
view:
interface bridge-aggregation
interface-number
• Enter S-channel interface view:
interface s-channel
interface-number.channel-id
• Enter S-channel aggregate interface
view:
interface schannel-aggregation
interface-number:channel-id
• Enter Layer 2 RPR logical interface
view:
interface rpr-bridge
interface-number
N/A
17. Configure the port to
operate in manual voice
VLAN assignment
mode.
undo voice-vlan mode auto
By default, a port operates in
automatic voice VLAN
assignment mode.
18. Set the link type of the
port.
• Set the port link type to access:
port link-type access
• Set the port link type to trunk:
port link-type trunk
• Set the port link type to hybrid:
port link-type hybrid
By default, each port is an
access port.
19. Assign the access,
trunk, or hybrid port to
the voice VLAN.
• For the access port:
port access vlan vlan-id
• For the trunk port:
port trunk permit vlan { vlan-id-list |
all }
• For the hybrid port:
port hybrid vlan vlan-id-list { tagged |
untagged }
After you assign an access
port to the voice VLAN, the
voice VLAN becomes the
PVID of the port.
20. (Optional.) Configure
the voice VLAN as the
PVID of the trunk or
hybrid port.
• For the trunk port:
port trunk pvid vlan vlan-id
• For the hybrid port:
port hybrid pvid vlan vlan-id
This step is required for
untagged incoming voice
traffic and prohibited for
tagged incoming voice traffic.
21. Enable the voice VLAN
feature on the port.
voice-vlan
vlan-id
enable
By default, the voice VLAN
feature is disabled.
Before you execute this
command, make sure the
specified VLAN already exists.
Enabling LLDP for automatic IP phone discovery
Step
Command
Remarks
22. Enter system view.
system-view
N/A
23. Enable LLDP for automatic
IP phone discovery.
voice-vlan track lldp
By default, LLDP for automatic IP
phone discovery is disabled.
