HPE ProLiant MicroServer Gen10 User Manual

Install the chassis cover
To prevent access to the front bezel lock and the internal components, install the chassis cover.
Install the chassis cover
Prerequisites
1. Verify that all internal cables are properly connected and are secured in their respective cable ties.
2. V
erify that the drive cables are not blocking the fan blades.
Procedure
1. Insert the tabs on the bottom left and right sides of the chassis cover into the corresponding slots on the
chassis.
2. Slide the chassis cover towards the front panel.
3. Install the chassis thumbscrews.
1
1
3
3
2
4. If removed, install the security padlock and/or the Kensington security lock.
For more information, see the lock documentation.
Install the system board assembly
To secure the system board inside the chassis, install the system board assembly.
Install the system board assembly
Prerequisites
Before you perform this procedure, make sure that you have a T-15 T
orx screwdriver available.
Procedure
1. Slide the system board assembly into the chassis.
2. Press against the system board assembly until it clicks into place.
3. Install the system board assembly screw.
Install the chassis cover 27

HPE ProLiant MicroServer Gen10 Specifications

General

Product Line	HPE ProLiant
Server Type	MicroServer
Maximum Memory	32 GB
Memory Slots	2
Expansion Slots	1 PCIe 3.0 x8 slot
Form Factor	Ultra Micro Tower
Processor	AMD Opteron X3000 series
Memory Type	DDR4 ECC UDIMM
Storage	4 LFF non-hot plug drive bays
Network	2 x 1GbE ports
Power Supply	200W Non-Hot-Plug, Non-Redundant Power Supply
Dimensions	23.5 x 23 x 25.4 cm
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Management	HPE iLO Standard
RAID Support	HPE Smart Array S100i SR Gen10 (RAID 0, 1, 10)
