1 2 3
7. After five seconds, remove the jumper from pins 1 and 2, and move it back to the default position on pins
2 and 3.
321
8. Install the system board assembly on page 27.
9. Install the chassis cover on page 27.
10. Connect all peripheral cables to the server
.
11. Connect the power cord to the server power jack, and then to the AC source.
12.
Power up the server on page 22.
Embedded UEFI Shell
The system BIOS in this
server
includes an Embedded UEFI Shell in the ROM. The UEFI Shell environment
provides an API, a command-line prompt, and a set of CLIs that allow scripting, file manipulation, and system
information. These features enhance the capabilities of the Aptio Setup Utility.
For more information, see the UEFI Shell Specification on the UEFI website:
http://www.uefi.org/specifications
62 Embedded UEFI Shell

Table of Contents

Other manuals for HPE ProLiant MicroServer Gen10

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HPE ProLiant MicroServer Gen10 and is the answer not in the manual?

HPE ProLiant MicroServer Gen10 Specifications

General IconGeneral
Product LineHPE ProLiant
Server TypeMicroServer
Maximum Memory32 GB
Memory Slots2
Expansion Slots1 PCIe 3.0 x8 slot
Form FactorUltra Micro Tower
ProcessorAMD Opteron X3000 series
Memory TypeDDR4 ECC UDIMM
Storage4 LFF non-hot plug drive bays
Network2 x 1GbE ports
Power Supply200W Non-Hot-Plug, Non-Redundant Power Supply
Dimensions23.5 x 23 x 25.4 cm
Operating System SupportMicrosoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
ManagementHPE iLO Standard
RAID SupportHPE Smart Array S100i SR Gen10 (RAID 0, 1, 10)
