HPE ProLiant MicroServer Gen10 User Manual

Hardware options installation
This chapter provides detailed instructions on how to install hardware options.
For more information on supported options, see the product QuickSpecs on the HPE ProLiant MicroServer
Gen10 website at:
http://www.hpe.com/server/microserver
To view the warranty for your server and supported options, see Warranty information.
Introduction
If more than one option is being installed, read the installation instructions for all the hardware options and
identify similar steps to streamline the installation process.
WARNING:
To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system
components to cool before touching them.
CAUTION:
To prevent damage to electrical components, properly ground the server before beginning any
installation procedure. Improper grounding can cause electrostatic discharge.
Drive support information
This server only supports non-hot-plug drives. These drives are not designed to be installed or removed from
the server while the system is still powered on. Power of
f the server before installing or removing a drive
option.
From a drive interface standpoint, the embedded Marvell 88SE9230 PCIe to SAT
A 6Gb/s Controller supports
SATA drives.
From a form factor standpoint, the server drive bays support 3.5-inch LFF drives. To support 2.5-inch SFF
drives,
install the SFF-to-LFF drive converter option.
To support a 7-mm SA
TA solid state drive in the media bay,
install the SSD enablement kit.
Drive installation guidelines
•
Populate drive bays based on the drive numbering sequence. Start from the
drive bay with the lowest
device number.
• All drives grouped into the same drive array must meet the following criteria:
◦
They must be either all hard drives or all solid state drives.
◦ Drives should be the same capacity to provide the greatest storage space efficiency when drives are
grouped together into the same drive array.
• The system automatically sets all device numbers.
Installing an LFF drive
About this task
To add internal data storage to the server
, install one or more LFF drives in the drive bays.
Hardware options installation 31

HPE ProLiant MicroServer Gen10 Specifications

General

Product Line	HPE ProLiant
Server Type	MicroServer
Maximum Memory	32 GB
Memory Slots	2
Expansion Slots	1 PCIe 3.0 x8 slot
Form Factor	Ultra Micro Tower
Processor	AMD Opteron X3000 series
Memory Type	DDR4 ECC UDIMM
Storage	4 LFF non-hot plug drive bays
Network	2 x 1GbE ports
Power Supply	200W Non-Hot-Plug, Non-Redundant Power Supply
Dimensions	23.5 x 23 x 25.4 cm
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Management	HPE iLO Standard
RAID Support	HPE Smart Array S100i SR Gen10 (RAID 0, 1, 10)
