HPE ProLiant MicroServer Gen10 User Manual

3. Slide the drive into the drive bay until it clicks into place.
Installing an SFF drive
About this task
To install SFF drives in the drive bays, install the SFF drive converter option. In general, SFF drives give
greater power and space savings. SFF drives can require as little as half the power and generate significantly
less heat than LFF drives.
Procedure
1. Power down the server on page 22.
2. Disconnect the power cord from the AC source, and then from the server.
3. Disconnect all peripheral cables from the server
.
4.
Remove the front bezel on page 23.
5. Install the SFF drive on page 34.
6. Install the front bezel on page 25.
7. Connect all peripheral cables to the server
.
8. Connect the power cord to the server power jack, and then to the AC source.
9.
Power up the server on page 22.
10. Determine the status of the server drives from the drive LED definitions.
11. T
o configure drive arrays, do one of the following:
Installing an SFF drive 33

HPE ProLiant MicroServer Gen10 Specifications

General

Product Line	HPE ProLiant
Server Type	MicroServer
Maximum Memory	32 GB
Memory Slots	2
Expansion Slots	1 PCIe 3.0 x8 slot
Form Factor	Ultra Micro Tower
Processor	AMD Opteron X3000 series
Memory Type	DDR4 ECC UDIMM
Storage	4 LFF non-hot plug drive bays
Network	2 x 1GbE ports
Power Supply	200W Non-Hot-Plug, Non-Redundant Power Supply
Dimensions	23.5 x 23 x 25.4 cm
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Management	HPE iLO Standard
RAID Support	HPE Smart Array S100i SR Gen10 (RAID 0, 1, 10)
