HPE ProLiant MicroServer Gen10 User Manual

Procedure
1. Power down the server on page 22.
2. Disconnect the power cord from the AC source, and then from the server.
3. Disconnect all peripheral cables from the server
.
4.
Remove the chassis cover on page 26.
5. Install the SSD on page 37.
6. Install the chassis cover on page 27.
7. Connect all peripheral cables to the server
.
8. Connect the power cord to the server power jack, and then to the AC source.
9.
Power up the server on page 22.
Install the SSD
Prerequisites
Before you perform this procedure, make sure that you have the following items available:
• T
-10 Torx screwdriver
• T-15 Torx screwdriver
• SSD enablement option kit. This kit includes:
◦ SSD tray
◦ SSD power cable
◦ SSD SATA cable
◦ T-10 screws (4, for securing the SSD)
◦ T-15 Torx screw (1, for securing the SSD tray)
• SSD option
Procedure
1. Place the SSD in the SSD tray, and then install the SSD screws.
1
2
2
2
2
2. Install the SSD assembly in the media bay, and then secure it with the screw.
Install the SSD 37

HPE ProLiant MicroServer Gen10 Specifications

General

Product Line	HPE ProLiant
Server Type	MicroServer
Maximum Memory	32 GB
Memory Slots	2
Expansion Slots	1 PCIe 3.0 x8 slot
Form Factor	Ultra Micro Tower
Processor	AMD Opteron X3000 series
Memory Type	DDR4 ECC UDIMM
Storage	4 LFF non-hot plug drive bays
Network	2 x 1GbE ports
Power Supply	200W Non-Hot-Plug, Non-Redundant Power Supply
Dimensions	23.5 x 23 x 25.4 cm
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Management	HPE iLO Standard
RAID Support	HPE Smart Array S100i SR Gen10 (RAID 0, 1, 10)
