HPE ProLiant MicroServer Gen10 User Manual

3. Disconnect all peripheral cables from the server.
4. Remove the chassis cover on page 26.
5. Install the DIMM on page 47.
6. Install the chassis cover on page 27.
7. Connect all peripheral cables to the server
.
8. Connect the power cord to the server power jack, and then to the AC source.
9.
Power up the server on page 22.
10. T
o configure the memory, use the
Aptio Setup Utility on page 59. Select
Chipset > South Bridge >
Memory Configuration.
Install the DIMM
Procedure
1. Open the DIMM slot latches.
2. Align the notch on the bottom edge of the DIMM with the keyed surface of the DIMM slot, and then fully
press the DIMM into the slot until the latches snap back into place.
The DIMM slots are structured to ensure proper installation. If you try to insert a DIMM but it does not fit
easily into the slot, you might have positioned it incorrectly. Reverse the orientation of the DIMM and insert
it again.
2
2
1
Expansion board options
The server has two low-profile, open-ended PCIe3 expansion slots. Use these slots to install additional
hardware capabilities such as:
• An HBA to enable advanced drive features.
•
A GPU to accelerate the processing speed of your applications.
• A network adapter with advanced Ethernet connectivity features.
Installing an expansion board
Procedure
1. Power down the server on page
22.
2. Disconnect the power cord from the AC source, and then from the server.
3. Disconnect all peripheral cables from the server.
4.
Remove the chassis cover on page 26.
Install the DIMM 47

HPE ProLiant MicroServer Gen10 Specifications

General

Product Line	HPE ProLiant
Server Type	MicroServer
Maximum Memory	32 GB
Memory Slots	2
Expansion Slots	1 PCIe 3.0 x8 slot
Form Factor	Ultra Micro Tower
Processor	AMD Opteron X3000 series
Memory Type	DDR4 ECC UDIMM
Storage	4 LFF non-hot plug drive bays
Network	2 x 1GbE ports
Power Supply	200W Non-Hot-Plug, Non-Redundant Power Supply
Dimensions	23.5 x 23 x 25.4 cm
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Management	HPE iLO Standard
RAID Support	HPE Smart Array S100i SR Gen10 (RAID 0, 1, 10)
