Storage controller 6 flashes
System board PCIe slots 7 flashes
Power backplane 8 flashes
Storage backplane 9 flashes
Power supply 10 flashes
PCIe expansion cards installed in riser board 11 flashes
Chassis 12 flashes
GPU card 13 flashes
SubsystemSubsystem LED behaviorLED behavior
Rear panel componentsRear panel components
ItemItem DescriptionDescription
1 Flexible Slot power supply 1 (hot-plug)
2 Flexible Slot power supply 2 (hot-plug)
3 Non-hot-plug power supply
4 Power cord strain relief clip
5 NIC 1/iLO Shared Network Port
6 Padlock eye
7 System fan
8 Kensington security slot
9 NIC port 2
