8. Disconnect the SATA-power Y-cable from the optical drive .
9. Remove the optical drive assembly from the media bay.
10. Remove the optical drive from the optical drive cage.
To replace the component, reverse the removal procedure.
Removing and replacing an internal USB deviceRemoving and replacing an internal USB device
ProcedureProcedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Disconnect all peripheral cables from the server.
4. Do one of the following:
