Fan mode behaviorFan mode behavior
The server supports only nonredundant fan mode. If a single fan fails or is missing, the following behaviors are exhibited:
The health LED flashes amber.
The operating system performs a graceful shutdown.
Media device screwsMedia device screws
There are eight T-15 Torx screws on the front panel. These screws are provided as spare screws for installing the USB RDX drive and
SATA optical drive options.
CAUTION:CAUTION:
The media device screws on the front panel are not compatible with a SAS LTO tape drive option. To prevent damage
to the drive, do not use these media device screws on a SAS LTO tape drive.
CablingCabling
Cabling guidelinesCabling guidelines
The cable colors in the cabling diagrams used in this chapter are for illustration purposes only.
Observe the following guidelines when working with server cables.
