a. Connect each power cord to the server.
b. Connect each power cord to the power source.
12. Power up the server.
Removing and replacing the non-hot-plug power supplyRemoving and replacing the non-hot-plug power supply
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available.
WARNING: WARNING: To reduce the risk of personal injury from hot surfaces, allow the power supply and the power supply blank
to cool before touching them.
ProcedureProcedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Disconnect all peripheral cables from the server.
4. Do one of the following:
If the server is in tower mode: Position the tower server for hardware configuration.
If the server is in rack mode: Remove the server from the rack .
5. Remove the front bezel .
6. Remove the access panel .
7. If installed, remove the air baffle .
8. Disconnect all power supply cables .
9. Remove the non-hot-plug power supply.
