HPE ProLiant ML30 Gen10

To Next Page

To Previous Page

Fan numberingFan numbering

Fan numberFan number Fan typeFan type

1 PCI fan (optional)

2 System fan

3 Heatsink fan

HPE ProLiant ML30 Gen10 Server Maintenance and Service Guide 111
