Cable colorCable color DescriptionDescription

Orange Mini-SAS cable with sideband connector

Blue Drive power cable

LFF hot-plug drive cabling with Flexible Slot power supplyLFF hot-plug drive cabling with Flexible Slot power supply

Cable colorCable color DescriptionDescription

Orange Drive power cable

HPE ProLiant ML30 Gen10 Server Maintenance and Service Guide 118
