Cable colorCable color DescriptionDescription

Orange Drive power cable

Blue Mini-SAS cable from controller port 1 to drive backplane port 1

Gold Mini-SAS cable from controller port 2 to drive backplane port 2

SFF hot-plug drive cabling for controller with Flexible Slot power supplySFF hot-plug drive cabling for controller with Flexible Slot power supply

Cable colorCable color DescriptionDescription

HPE ProLiant ML30 Gen10 Server Maintenance and Service Guide 122
