HPE ProLiant ML30 Gen10

To Next Page

To Previous Page

Cable colorCable color DescriptionDescription

Orange Power supply cable

Blue USB RDX drive power cable

Gold USB RDX drive cable

USB RDX drive with Flexible Slot power supply cablingUSB RDX drive with Flexible Slot power supply cabling

Cable colorCable color DescriptionDescription

HPE ProLiant ML30 Gen10 Server Maintenance and Service Guide 127
