b. Disconnect each power cord from the server.
3. Disconnect all peripheral cables from the server.
4. Do one of the following:
If the server is in tower mode: Position the tower server for hardware configuration.
If the server is in rack mode: Remove the server from the rack .
5. Remove the front bezel .
6. Remove the access panel .
7. If installed, remove the air baffle .
8. Disconnect the drive power and controller cables from the backplane .
9. Remove all drives.
10. Remove the drive cage.
Retain the screws for future use.
11. Remove the drive backplane.
Retain the screws for future use.
