6.10.6 Technical characteristics of the Lenord+Bauer sinusoidal encoder
SPECIFICATION VALUE
“U” rated supply voltage
5V DC ±5%
Operating temperature -30°C - 85°C (-22°F - 185°F)
Max. operating height 2000m (6500ft)
Signal input 128 pulses per rev + zero reference
A B signal output
500 mV peak-to-peak with average value “U ref.”=U/2
1 V peak-to-peak as difference of signals with average
value “U ref.” (see figures below)
A B signal phase difference 90° (a quarter of period)
Z signal output
500 mV peak compared with resting value
U ref. ±80mV
1 V peak as difference of signals with resting value U
ref.-160mV= 2.34V (see figures below)
