14.
Apply the gasket and the steel sheet cover
15.
Fix the cover using the four screws
8.4 REPLACING THE SHAFT KIT FOR MODELS ES919 ENCODER
8.4.1 Disassembly procedure
1.
Follow steps 1 to 13 of the disassembly
procedure for the standard models
2.
Loosen the four 4x25 screws of the encoder
box
