2.2 MAIN PARTS OF MODELS ES884 - ES888
1
2
7
5
12
3
9
10
1
8
8
6
4
11
1 Sensor area 7 Pneumatic connections
2 Pneumatic cylinder 8 M6 threaded bores for accessories
3 “Nose” 9 Shaft
4 Fixing surface 10 Tool hooking system
5 Pressurisation connector 11 Serial number
6 Framework 12 Electrical connectors
