11 LIST OF SPARE PARTS
HSD CODE DESCRIPTION
41805006
Sensor S1(apart from ES939)
4180500601
Sensor S2 (apart from ES939)
4180500602
Sensor S3 (apart from ES939)
5664H0016
Sensor S4 (apart from ES939)
5664H0026
Sensor S5
4180500601
Sensors S1, S2, S3, S4 for ES939
6390H0001
Kit for cooling with forced air, for models ES915, 919, 929
6390H0002
Kit for cooling with forced air, for models ES983 and ES988
5661H0009
Fan kit (complete with casing and protective cover)
for models ES915, 919, 929
3002A0515
TCEI M4X25 screws for fixing the fan kit 5661H0009
5661H0008
Fan kit (complete with casing and protective cover)
for models ES983 and ES988
3002A0577
TCEI M4X30 screws for fixing the fan kit 5661H0008
302006100
Schnorr washer for M4 screw, for fixing the two fan kits
6200H0050
“Signal + power” mobile connector
2138A0604
“Signals” mobile connector
2138A0607
“Power” mobile connector
2138A0229
“Encoder” mobile connector
2147A0404
Straight fitting for encoder connector
2147A0137
Elbow fitting for encoder connector
1401H0011
Rubber cover (D=110) to protect the inside of the spindle
1401H0010
Rubber cover (D=100) to protect the inside of the spindle ES939
1707H0030
ISO30 cone to protect the inside of the spindle
1707H0031
HSK F63 cone to protect the inside of the spindle
2161H0022
Cooling liquid Artic-Flu-5
i
SPARE SHAFT KIT
Spare shaft kits are available, to install in case of bearing wear.
The shaft kit has a shaft, bearings already run in, rotor, tie-rod and coupling system.
To obtain a shaft kit suitable for your own model, inform the HSD commercial office about
the spindle serial number
The serial number is usually stamped on the front flange or the framework front part (see
section 2)
