HSD ES939 - Page 132

HSD
5801H0056 ______________________________________________________________ 132/181
5.
Reassemble the cylinder unit, tightening the six
6x105 screws (with copper washer and
applying Loctite 222 on the thread), then
definitively tighten using a torque of 14Nm
6.
Spread a layer of Loctite 510 inside the seat of
the mounting plate bracket
7.
Block the bracket with the six screws
8.
Spread a layer of Loctite 510 on the mounting
plate bracket
