HSD
5801H0056 ______________________________________________________________ 134/181
3.
Disconnect all the pneumatic connections and
the relative sensors
4.
Open all the internal movable connections
(inductive sensors and electric fan)
Loosen the two screws indicated in the figure
and remove the pressurisation block
5.
Variation ES939: loosen the four screws
indicated in the figure and remove the
pneumatic block
