HSD ES939 - Page 155

HSD
5801H0056 ______________________________________________________________ 155/181
3.
Detach the encoder connector
4.
Loosen the two 3x8 screws of the encoder
reader bracket. Disassemble the bracket-encoder
reader assembly.
5.
Assemble the new bracket-encoder reader
assembly
6.
Block with two 3x8 screws + a knurled washer
