HSD ES939 - Page 36

HSD
5801H0056 _______________________________________________________________ 36/181
H1423H0225 Rev.01 (SP.110.130.4H)
Rated voltage (*) V 380 380 380 380 380 380
Rated frequency Hz 400 500 600 667 733 800
Rated speed rpm 12,000 15,000 18,000 20,000 22000 24,000
Duty type
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
Rated power kW 9
10.5
9
10.5
8
9.4
7.2
8.6
6.3
7.5
5.4
6.3
Rated torque Nm 7.2
8.7
5.7
6.7
4.2
5
3.4
4.1
2.7
3.3
2.2
2.5
Rated current A 21
25.3
19.2
22.5
17.5
20
15.8
19
14
17
12.9
14.7
Rated output η
0.85
Power factor cos ϕ
0.85
Number of poles 4
Type of insulation F
Type of cooling
Elettroventola / Elektrolüfter / Cooling fan
Weight of
SHORT NOSE version
kg ~ 26
Weight of
LONG NOSE version
kg ~ 31
[(*) supplied by inverter]
