HSD ES939 - Page 46

HSD
5801H0056 _______________________________________________________________ 46/181
H1423H0309 RevP2 SP110.131.47
Rated voltage (*) V
380 380 380 380 380
Rated frequency Hz
400 600 667 800 867
Rated speed rpm
12,000 18,000 20,000 24,000 26000
Duty type
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
Rated power kW
16
18
12
14
10.8
12.7
8.2
10
7
8.7
Rated torque Nm
12.7
14.3
6.4
7.4
5.2
6.1
3.3
4.0
2.6
3.2
Rated current A
31
35.5
23
27
21
25
15.8
20
14
17
Rated output η 0.90
Power factor cos ϕ 0.79
Number of poles
4
Type of insulation
F
Type of cooling
Raffreddamento a liquido / Flüssigkeit / Liquid cooling
Weight of
SHORT NOSE version
kg
30
Weight of
LONG NOSE version
kg
34
[(*) supplied by
inverter]
