HSD ES939 - Page 50

HSD
5801H0056 _______________________________________________________________ 50/181
H1423H0317 Rev.00 (SP.110.131.48)
R
ated voltage (*) V
380 380 380 380
R
ated frequency Hz
200 400 600 800
R
ated speed rpm
6000 12,000 18,000 24,000
D
uty type
S1 cont S6 40% S1 cont S6 40% S1 cont S6 40% S1 cont S6 40%
R
ated powe
r
kW
9
10
8
9
6
6.5
4.5
5.2
R
ated torque Nm
14.3
15.9
6.4
7.2
3.2
3.4
1.8
2.1
R
ated current A
18.6
20.7
17.1
21.7
12.7
13.6
10
11.5
R
ated output η 0.88 0.86 0.80 0.75
P
ower factor co
s
ϕ 0.8
N
umber of pole
s
4
T
ype of insulation
F
T
ype of cooling
Raffreddamento a liquido / Flüssigkeit / Liquid cooling
W
eight of
S
HORT NOSE version
kg
~ 30
W
eight of
ONG NOSE version
kg
~ 34
[(*) supplied by inverter]
