Table 13-4 Technical specifications of FE electrical interfaces
Item Specification Requirement
Interface rate 100 Mbit/s
Others Complies with IEEE 802.3.
13.3 Technical Specifications of the 10 GE Interfaces
The ATN 950B supports 10GE optical interfaces. This section describes the technical
specifications of the 10GE optical interfaces.
Table 13-5 lists the technical specifications of 10GE optical interfaces.
Table 13-5 Technical specifications of the 10GE optical interface
Item Specification
Optical interface type Two-fiber bidirectional interface
10GE
(10 km)
10GE
(40 km)
10GE
(80 km)
Fiber type Single-mode Single-mode Single-mode
Working wavelength
range (nm)
1310 1550 1550
Mean launched
optical power (dBm)
-6 to -1 -1 to 2 0 to 4
Receiver sensitivity
(dBm)
–14.4 –15 –24
Minimum overload
(dBm)
0.5 –1 –7
Minimum extinction
ratio (dB)
6 8.2 9
Optical module code S4015772 S4015776 S4015794
NOTE
For details of the optical module, see 7.2 Optical Module Labels.
13.4 Technical Specifications of E1 Electrical Interfaces
This section describes technical specifications of E1 electrical interfaces.
Table 13-6 lists the technical specifications of the E1 interfaces.
