Step 2 Determine the position of the SD card to be replaced.
Figure 7-110 shows the positions of the two SD cards. SD card 1 is above the SD card board,
and SD card 2 is below the SD card board.
l If the server has only one microSD card and the OS is installed on the card, migrate the
data on the SD card to another storage device before the replacement.
l If the server has two microSD cards, install the new microSD card in the same slot as the
replaced one.
Figure 7-110 SD card position
Step 3 Remove the SD card to be replaced. For details, see 7.47 Removing an SD Card.
If SD card 2 needs to be replaced, remove the SD card board first.
Step 4 Take the spare SD card out of its ESD bag.
NOTE
l Ensure that the spare microSD card contains no data.
Step 5 Install the SD card.
l If SD card 1 needs to be replaced, perform 1.
l If SD card 2 needs to be replaced, perform 1 to 3.
1. Insert the SD card into the board. See Figure 7-111.
