RMS-SNMP01A SNMP Card
User Manual
4 Managing the UPS on the WebUI
Copyright © Huawei Technologies Co., Ltd.
If a third-party NMS complying with the RFC1628 standard, such as UNMS of Generex, is adopted,
download the UPS-RFC1628-MIB file. For details about how a third-party NMS manages the UPS,
see 7 Managing the UPS by Using the NMS Complying with RFC1628 Standard.
If a third-party NMS complying with Huawei standard is adopted, download the
HUAWEI_UPS_MIB file. For details about the function of a third-party NMS managing UPS, see 6
Managing the UPS by Using the NMS Complying with Huawei Standard.
Under NMS Address and Permission Settings, you can add NMS information for accessing
the SNMP card. The information includes NMS Addr., Permission, as shown in Figure 4-36.
SNMP TRAP can be used to add Trap Address and Trap port, select SNMP version, and set
community, as shown in Figure 4-37.
Figure 4-36 Add NMS Address Info dialog box
Figure 4-37 Add SNMP TRAP
