Huawei SUN2000 MAP0 Series - Optional) Setting the Energy Measurement Mode

Table 7-4 Setting common parameters
Parameter Scenario Description Operation
Grid-tied
point
control
Many regions impose a limit on
the feed-in power of a power
generation system. Therefore, a
power meter is required to
measure the power of the grid-
tied point to control the output
of the inverter in real time,
ensuring that the feed-in power
meets the power requirement
allowed by the power grid.
● Smart Dongle networking:
Choose Commission Device,
tap Power adjustment, and
set related parameters. For
details about the parameter
description and GUI settings,
see section "Parameter
Settings" in Residential
Smart PV Solution
Commissioning Manual
(Smart Dongle).
● EMMA networking: Choose
Commission Device, tap
Power adjustment, and set
related parameters. For
details about the parameter
description and GUI settings,
see section "Parameter
Settings" in Residential
Smart PV Solution User
Manual (EMMA).
Battery
parameter
setting
If a battery is connected to the
system, you need to add the
battery and set battery
parameters.
Capacity
control
This function applies to areas
that have peak demand
charges. The capacity control
function allows you to lower
the peak power drawn from
grid in maximum self-
consumption or TOU mode
during peak hours, reducing
electricity fees.
To set more parameters, tap Settings. For details about the parameters, see
FusionSolar App and SUN2000 App Device Commissioning Guide. You can also
scan the QR code to obtain the document.
7.3.2 (Optional) Setting the Energy Measurement Mode
Function Description
This function is used to congure dierent energy measurement modes for
dierent areas. After power meters are installed, you can congure the
measurement modes to implement balanced and unbalanced measurement of
energy.
