Figure 5-40 Securing the signal cable connector
----End
5.7.8 Connecting the Battery Signal Cable
Cable Connection
The following gure shows the cable connection between the inverter and the
battery.
Figure 5-41 Cable connection
SUN2000-(5K-12K)-MAP0 Series
User Manual 5 Electrical Connections
Issue 01 (2024-05-13) Copyright © Huawei Digital Power Technologies Co., Ltd. 81
