Table 5-1 Component description
No. Component Description Source
A PV module ● A PV string consists of PV
modules connected in series.
● The inverter supports two PV
string inputs.
Prepared by the
customer
B Smart PV
Optimizer
Supported models:
SUN2000-(600W-P, 450W-P2)
and MERC-600W-PA0
[1]
Purchased from
Huawei
C
Smart Dongle
[2]
Supported models:
● WLAN-FE Smart Dongle:
SDongleA-05
● 4G Smart Dongle:
SDongleB-06
Purchased from
Huawei
D AC switch To ensure that the inverter can
be safely disconnected from the
power grid when an exception
occurs, connect an AC switch to
the AC side of the inverter. Select
an appropriate AC switch in
accordance with local industry
standards and regulations.
Huawei recommends the
following switch specications:
It is recommended that you use
a three-phase AC circuit breaker
with a rated voltage greater than
or equal to 415 V AC and a rated
current of:
● 5K and 6K: 16 A
● 8K: 25 A
● 10K and 12K: 32 A
Prepared by the
customer
E
Power meter
[3]
The recommended power meter
models are DTSU666-H (250
A/100 A), DTSU666-HW,
YDS60-80, DTSU71, DHSU1079-
CT, and YDS60-C24
[4]
.
Purchased from
Huawei
F
EMMA
[5]
Supported models: EMMA-A01
and EMMA-A02
Purchased from
Huawei
