No. Component Description Source
G SmartGuard The SmartGuard can be used to
switch between the on-grid and
o-grid states of the inverter.
Supported models:
SmartGuard-63A-T0 and
SmartGuard-63A-AUT0
Purchased from
Huawei
H Inverter Select a proper model as
required.
Purchased from
Huawei
I Rapid shutdown
switch
Select a proper model as
required.
Prepared by the
customer
J Power grid
scheduling device
Select the device that meets the
power grid scheduling
requirements.
Provided by the
local power grid
company
K Battery The inverter can connect to the
LUNA2000.
Purchased from
Huawei
Note [1]: The SUN2000-(600W-P, 450W-P2) and MERC-600W-PA0 cannot be
used together under the same inverter.
Note [2]: For details about how to operate a WLAN-FE Smart Dongle
SDongleA-05, see SDongleA-05 Smart Dongle Quick Guide (WLAN-FE). For
details about how to operate a 4G Smart Dongle SDongleB-06, see
SDongleB-06 Smart Dongle Quick Guide (4G). You can obtain these
documents at https://support.huawei.com/enterprise by searching for models.
Note [3]: For details about how to operate a power meter, see DTSU666-HW
Smart Power Sensor Quick Guide, DTSU666-H 100 A and 250 A Smart Power
Sensor User Manual, YDS60-80 Smart Power Sensor Quick Guide, DTSU71
Smart Power Sensor Quick Guide, DHSU1079-CT Smart Power Sensor Quick
Guide, or YDS60-C24 Smart Power Sensor Quick Guide.
Note [4]: Retain the default baud rates for the DTSU666-H and YDS60-C24
power meters. If they are changed, the power meters may go oine, generate
alarms, or aect the inverter output power.
Note [5]: For details about how to operate the EMMA, see EMMA-(A01, A02)
Quick Guide.
Table 5-2 Cable description
No
.
Name Type Conductor Cross-
Sectional Area
Outer
Diameter
Sourc
e
1 DC input
power cable
Common
outdoor PV
cable in the
industry
4–6 mm
2
5.5–9 mm Prepar
ed by
the
custo
mer
