Figure 2-2 Typical networking
(A) PV string (B) SUN2000 (C) AC switch
(D) AC PDU (E) Power meter (F) Power grid
(G) 4G Smart Dongle (H) WLAN-FE Smart
Dongle
(I) Router
(J) FusionSolar
management system
(K) FusionSolar app (L) Load
(M) Power grid
scheduling device
(N) Rapid shutdown
switch
(O) Optimizer
(P) Slave devices
SUN2000-(12K-25K)-MB0 Series
