Huawei SUN2000 MB0 Series User Manual

No. Component Description Source
I
Smart Dongle
[2]
Supported models:
● WLAN-FE Smart Dongle:
SDongleA-05
● 4G Smart Dongle:
SDongleB-06
Purchased from
Huawei
J Battery Reserved ports /
Note [1]: For details about how to operate a power meter, see DTSU666-HW
Smart Power Sensor Quick Guide, DTSU666-H 100 A and 250 A Smart Power
Sensor User Manual, YDS60-80 Smart Power Sensor Quick Guide, and
YDS60-C24 Smart Power Sensor Quick Guide.
Note [2]: For details about how to operate a WLAN-FE Smart Dongle
SDongleA-05, see SDongleA-05 Smart Dongle Quick Guide (WLAN-FE). For
details about how to operate a 4G Smart Dongle SDongleB-06, see
SDongleB-06 Smart Dongle Quick Guide (4G). You can obtain these
documents at https://support.huawei.com/enterprise by searching for models.
Note [3]: SUN2000-(600W-P, 450W-P2) and MERC-(1300W, 1100W)-P cannot
be used together.
Note [4]: Retain the default baud rates for the DTSU666-H and YDS60-C24
power meters. If they are changed, the power meters may go
oine, generate
alarms, or
aect the inverter output power.
Table 5-2 Cable description
No.
Name Type Conductor Cross-
Sectional Area
Outer
Diameter
1 PE cable Single-core
outdoor
copper cable
12K: ≥ 6 mm
2
15K–25K: ≥ 10 mm
2
-
2 AC output
power cable
Five-core
outdoor
copper cable
12K: 6–16 mm
2
15K–25K: 10–16 mm
2
11–26 mm
3 DC input power
cable
Common
outdoor PV
cable in the
industry
4–6 mm
2
5.5–9 mm
4 (Optional)
RS485
communications
cable
Two-core
outdoor
shielded
twisted pair
cable
0.2–1 mm
2
(0.5 mm
2
recommended)
4–11 mm
SUN2000-(12K-25K)-MB0 Series
User Manual 5 Electrical Connections
Issue 01 (2023-04-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 38

Huawei SUN2000 MB0 Series Specifications

General

Type	String Inverter
Max Input Voltage	1100 V
MPPT Voltage Range	200 V - 1000 V
Number of MPPTs	2
Max Input Current per MPPT	26 A
Rated Output Frequency	50 Hz / 60 Hz
Max Efficiency	98.6%
Operating Temperature Range	-25°C to +60°C
Protection Degree	IP65
Cooling	Natural Convection
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
Cooling Method	Natural Convection
Protection Level	IP65
Model	SUN2000
Rated Output Voltage	230 V / 400 V
Humidity	0% - 100%
Communication	RS485
