Figure 2-4 UPS conceptual diagram in bypass mode
2.2.2.3 Battery Mode
If the mains input is abnormal or the rectier becomes abnormal, the UPS
transfers to battery mode. The power module obtains DC power from batteries,
and the power is converted into AC output by the inverter.
