Figure 3-48 Connecting signal cables in a dual-bus system
Step 2 Connecting the signal cables to each single UPS in a parallel system.
----End
3.5 Verifying the Installation
Table 3-5 lists check items.
If the check results of listed items 8 and 9 in Table 3-5 do not meet the
acceptance criteria, the UPS may be damaged.
Table 3-5 Check items and acceptance criteria
No.
Item Acceptance Criteria
01 UPS installation The UPS is securely installed and does
not tilt due to vibration.
UPS5000-E-(30 kVA–120 kVA)-FM
User Manual 3 Installation
Issue 03 (2022-01-30) Copyright © Huawei Technologies Co., Ltd. 84
