Indicator Color Status Description
O The bypass software is being upgraded.
Alarm
indicator
Yellow Steady
on
A minor alarm is generated for the bypass.
O There is no minor alarm for the bypass, or the
software is being upgraded.
Fault
indicator
Red Steady
on
A critical alarm is generated for the bypass.
O There is no critical alarm for the bypass, or
the software is being upgraded.
Functions
The bypass module supplies power in the following cases:
The UPS is set to ECO mode and the bypass voltage is within the specied range.
The power module overload exceeds the time limit.
Both the active and standby ECMs are abnormal.
The system fails to run properly.
The power supply is switched to the bypass manually.
Specications
● Dimensions (H x W x D): 130 mm x 420 mm x 500 mm
● Weight: 19 kg
● Rated output capacity: 200 kVA
