E.10 Part. N. 8000 H0364 (09-2008)
GENERAL OPERATIONS
5) Place a vessel on the right side of the motorcycle, under the coolant draining
screw (1). Using a 8 mm wrench, FIRST remove the screw (1) then SLOWLY
open the R.H. radiator cap (2); slope the motorcycle on the right side to drain the
coolant easily in the vessel. Loosen lower clamps (3) of the hoses that connect
the radiators to the engine. Loosen the clamp (4) of the upper hose that con-
nects the L.H. radiator to the water pump.
1
3
4
