• In case of Two Eye Tracing, the value of FPD will be automatically transmitted
and displayed.
• In case of pattern tracing, be sure to change the standard value to the actual
Bridge Size.
• In case of One Eye tracing, it will be helpful to use Bridge Size Input function in
Layout Mode. (It is much easier to measure the Bridge Size)
• Measure the Bridge Size as (B) instead of (A). Remember that the Bridge Size
is not from frame to frame, but from lens to lens,
•
Blocking Job on the Lens for Frame
Change should be executed on Optical
Center.
• Maximum 15 working data are stored automatically into the internal memory.
That includes all information such as traced data, layout data, edging data, etc.
Therefore, these data could be recovered after unexpected electrical failure.
• In case more than, 15 data is accumulated, it will delete the data according to
First In First Out basis.
