74 MAXPRO200 Instruction Manual 807700 Revision 1

Installation

Supply gas hoses

Air

Oxygen

Nitrogen

Caution: Never use teflon tape

Part number Length Part number Length

024671 3 m (10 ft) 024740 25 m (82 ft)

024658 4.5 m (15 ft) 024744 35 m (115 ft)

024659 7.5 m (25 ft) 024678 45 m (150 ft)

024765 10 m (35 ft) 024680 60 m (200 ft)

024660 15 m (50 ft) 024767 75 m (250 ft)

024766 20 m (65 ft)

Part number Length Part number Length

024607 3 m (10 ft) 024738 25 m (82 ft)

024204 4.5 m (15 ft) 024450 35 m (115 ft)

024205 7.5 m (25 ft) 024159 45 m (150 ft)

024760 10 m (35 ft) 024333 60 m (200 ft)

024155 15 m (50 ft) 024762 75 m (250 ft)

024761 20 m (65 ft)

Part number Length Part number Length

024210 3 m (10 ft) 024739 25 m (82 ft)

024203 4.5 m (15 ft) 024451 35 m (115 ft)

024134 7.5 m (25 ft) 024120 45 m (150 ft)

024211 10 m (35 ft) 024124 60 m (200 ft)

024112 15 m (50 ft) 024764 75 m (250 ft)

024763 20 m (65 ft)
