Hypertherm Powermax 65 Operator's Manual

SPECIFICATIONS
powermax 65/85 Operator Manual 1-5
Component weights
65 A CSA 65 A CE 85 A CSA 85 A CE
lbs (kg) lbs (kg) lbs (kg) lbs (kg)
Power supply 54.1 (24.5) 47.0 (21.3) 59.9 (27.2) 50.4 (22.8)
65/85 A
lbs (kg)
Hand torch 25 ft (7.6 m) 6.8 (3.1)
Hand torch 50 ft (15 m) 12.2 (5.5)
Hand torch 75 ft (23 m) 17.6 (8.0)
Machine torch 25 ft (7.6 m) 7.6 (3.4)
Machine torch 50 ft (15 m) 13.2 (6.0)
Machine torch 75 ft (23 m) 18.8 (8.5)
65 A 85 A
lbs (kg) lbs (kg)
Work lead 25 ft (7.6 m) 2.8 (1.3) 6.8 (3.1)
Work lead 50 ft (15 m) 5.0 (2.3) 7.5 (3.4)
Work lead 75 ft (23 m) 6.9 (3.1) 10.6 (4.8)

Hypertherm Powermax 65 Specifications

General

Open Circuit Voltage (OCV)	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Maximum Cut Capacity (Mild Steel)	1" (25 mm)
Input Voltage	200-600 V, 1/3-PH, 50/60 Hz
Output Current	20 – 65 A
Duty Cycle	50% @ 65 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Torch Lead Length	25 ft (7.6 m)
Maximum Cut Capacity (Aluminum)	5/8" (16 mm)
Severance Cut Capacity (Mild Steel)	1-1/4" (32 mm)
Maximum Severance Thickness	1-1/4 in (32 mm)
Gas Type	Air/Nitrogen
Torch Options	Hand Torch, Mechanized Torch
