SPECIFICATIONS
powermax 65/85 Operator Manual 1-13
Powermax85 cutting specifications
Handheld cut capacity (material thickness)
Recommended cut capacity at 20 ipm (500 mm/min) 1 in (25 mm)
Recommended cut capacity at 10 ipm (250 mm/min) 1-1/4 in (32 mm)
Severance capacity at 5 ipm (125 mm/min) 1-1/2 in (38 mm)
Mechanized pierce capacity (material thickness)
Pierce capacity (for edge starts, the capacities are the
same as the handheld capacities)
3/4 in (19 mm)
Maximum cut speed* (mild steel)
1/4 in (6 mm) 200 ipm (5500 mm/min)
1/2 in (12 mm) 70 ipm (2000 mm/min)
3/4 in (19 mm) 36 ipm (900 mm/min)
1 in (25 mm) 21 ipm (550 mm/min)
1-1/4 in (32 mm) 13 ipm (330 mm/min)
Gouging capacity
Metal removal rate on mild steel 19.5 lbs/hr (8.8 kg/hr)
Duramax series torch weights (refer to “Component weights” on page 1-5)
Duty cycle and voltage information (refer to “Powermax85 power supply ratings” on
page 1-8)
* Maximum cut speeds are the results of Hypertherm’s laboratory testing. Actual cutting speeds
may vary based on different cutting applications.

Hypertherm Powermax 65 Specifications

General

Open Circuit Voltage (OCV)	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Maximum Cut Capacity (Mild Steel)	1" (25 mm)
Input Voltage	200-600 V, 1/3-PH, 50/60 Hz
Output Current	20 – 65 A
Duty Cycle	50% @ 65 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Torch Lead Length	25 ft (7.6 m)
Maximum Cut Capacity (Aluminum)	5/8" (16 mm)
Severance Cut Capacity (Mild Steel)	1-1/4" (32 mm)
Maximum Severance Thickness	1-1/4 in (32 mm)
Gas Type	Air/Nitrogen
Torch Options	Hand Torch, Mechanized Torch
