Hypertherm Powermax 65 Operator's Manual

powermax 65/85 Operator Manual 3-1
Section 3
TORCH SETUP
In this section:
Introduction ......................................................................................................................................................... 3-3
Consumable life .................................................................................................................................................. 3-3
Hand torch setup ............................................................................................................................................... 3-4
Choose the hand torch consumables ................................................................................................ 3-5
Hand torch consumables ...................................................................................................................... 3-6
Install the hand torch consumables ..................................................................................................... 3-7
Machine torch setup.......................................................................................................................................... 3-8
Converting an M65/M85 torch to an M65m/M85m torch ............................................................ 3-9
Mount the torch ......................................................................................................................................3-11
Choose the machine torch consumables ........................................................................................3-14
Machine torch consumables ...............................................................................................................3-14
Install the machine torch consumables ............................................................................................3-17
Aligning the torch ..................................................................................................................................3-17
Connecting an optional remote-start pendant ...............................................................................3-18
Connecting an optional machine interface cable ...........................................................................3-19
Connecting the torch lead .............................................................................................................................3-24

Hypertherm Powermax 65 Specifications

General

Open Circuit Voltage (OCV)	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Maximum Cut Capacity (Mild Steel)	1" (25 mm)
Input Voltage	200-600 V, 1/3-PH, 50/60 Hz
Output Current	20 – 65 A
Duty Cycle	50% @ 65 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Torch Lead Length	25 ft (7.6 m)
Maximum Cut Capacity (Aluminum)	5/8" (16 mm)
Severance Cut Capacity (Mild Steel)	1-1/4" (32 mm)
Maximum Severance Thickness	1-1/4 in (32 mm)
Gas Type	Air/Nitrogen
Torch Options	Hand Torch, Mechanized Torch
