Hypertherm Powermax 65 Operator's Manual

TORCH SETUP
powermax 65/85 Operator Manual 3-49
65A Unshielded Air flow rate - slpm/scfh
Stainless Steel
Hot 160 / 340
Cold 220 / 470
Metric
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
2
2.0
5.0 250
0.1 7950 117 12800 119
3 0.2 6600 118 10600 119
4
0.5
5050 119 8200 119
6 2300 121 3800 120
8 0.7 1400 123 2400 121
10 6.0 300 0.7 920 126 1550 123
12
Edge Start
710 130 1150 127
16 480 135 630 132
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
in in % seconds ipm Volts ipm Volts
16GA
0.08
0.20 250
0.1
340 116 540 118
10GA 235 118 380 119
3/16 in 0.2 150 120 240 119
1/4 in 0.5 75 121 125 120
3/8 in 0.24 300 0.7 38 125 65 122
1/2 in
Edge Start
25 132 40 128
5/8 in 19 135 25 132

Hypertherm Powermax 65 Specifications

General

Open Circuit Voltage (OCV)	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Maximum Cut Capacity (Mild Steel)	1" (25 mm)
Input Voltage	200-600 V, 1/3-PH, 50/60 Hz
Output Current	20 – 65 A
Duty Cycle	50% @ 65 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Torch Lead Length	25 ft (7.6 m)
Maximum Cut Capacity (Aluminum)	5/8" (16 mm)
Severance Cut Capacity (Mild Steel)	1-1/4" (32 mm)
Maximum Severance Thickness	1-1/4 in (32 mm)
Gas Type	Air/Nitrogen
Torch Options	Hand Torch, Mechanized Torch
